Carden CL TL 11 LED accent track light on track, aimable cylindrical head in black finish

Your configuration

Updates with your selection in “Configure & add to quote”

Commercial

CL TL 11

Name: CL TL 11
Brand: Carden Lighting
SKU: CL-TL11-10W-5CCT

Accent LED track light with on-site selectable color temperature

Power10 – 30 W

Efficacy100 lm/W

Flux800 – 1,000 lm (10 W) · 1,500 lm…

CCT2700 – 5000 K

CRIRa 90

LED accent track light for 3-wire single-circuit track, commercial grade for North America (120 V). A single fixture adjusts its color temperature among 5 values (2700–5000 K) with a DIP switch at installation, and changes its beam angle (24/30/36/60°) with an interchangeable lens in the field; it adapts to each scene without replacing the equipment. CRI 90+, TRIAC dimming, 3-in-1 track adapter (H/J/L types) and white, black or gold finishes. Efficacy up to 100 lm/W. ETL certified (Intertek/cETLus) and suitable for indoor use (dry location).

Certifications

ETLcETLus

Does your project require another standard? We build to your specification.

Request a quote Request data sheet Request IES files

5-year warrantyResponse in under 24 h

Photometric data (IES/LDT) and datasheet available on request: we send them in under 24 h. Or write to us by email →

Design your space with the photometric studyBetaCheck that your project meets the norm: free, in minutes.

Your configuration

Updates with your selection in “Configure & add to quote”

Configure & add to quote

Power

Light color

We manufacture any colour temperature. If the one your project needs isn't listed, ask for it and we'll build it.

Mounting

Other / extra requirement

Quantity

Where it's used

Retail: accent track spot to highlight products, windows and new-arrival tables; the interchangeable beam (24/30/36/60°) goes from spot accent to general wash and the selectable CCT adapts the warmth to each season or store zone, without changing the fixture.Offices and corporate: directional lighting for receptions, showrooms and brand walls; the color temperature is set by zone with the DIP switch (neutral 4000 K in work areas, warm 3000 K in lounges) on the same single-circuit track.Hospitality and restaurants: accents on art, bars, buffets and textured walls in lobbies and dining rooms; CRI 90+ for true color of food, textiles and finishes, with the head in black, gold or white to blend into the interior design.Façade and indoor architectural accent: highlighting columns, niches, moldings and architectural surfaces in dry interiors; the beam angle is changed in the field to adjust emphasis and spread without replacing the head or the track.Premium residential: living rooms, dining rooms, open kitchens and corridors of homes and penthouses; TRIAC dimming compatible with common wall dimmers and selectable color temperature to go from day scenes to night scenes.

Featured benefits

(1) 5 color temperatures (2700–5000 K) that you adjust on site with the DIP switch, without replacing the fixture · (2) field-interchangeable beam lens (24/30/36/60°) to go from spot accent to general wash · (3) CRI 90+ for faithful color in retail, art and food · (4) TRIAC dimming compatible with common wall dimmers · (5) 3-in-1 track adapter (H/J/L) and 3 finishes (white/black/gold) to blend into any track and interior

Specifications

Electrical specifications

Wattage: 10–30 W
Input voltage: 120 VAC (North America)
Frequency: 60 Hz
Dimming: TRIAC (compatible with phase-cut wall dimmers)
Driver: Integrated

Photometric specifications

Luminous flux: 800–1,000 lm (10 W) · 1,500 lm (15 W) · 2,000 lm (20 W) · 2,500 lm (25 W) · 3,000 lm (30 W): ±10% tolerance, white finish @4000 K (black finish −10-15%)
Efficacy: 100 lm/W
CCT: 2700–5000 K
CRI: Ra 90

Physical, materials & mounting

Diffuser / optics: Interchangeable beam lens (24/30/36/60°), replaceable on site
Hardware: Rotating/tilting head on a track mount (track adapter included)
Finishes: White · black · gold
Mounting: 3-wire single-circuit track (standard Halo type) via a 3-in-1 adapter that converts to H / J / L track types
Dimensions: (by size): 10 W = Ø65 mm × 156.8 mm body (overall height with adapter 237.7 mm) · 15/20/25 W = Ø85 mm × 177.7 mm · 30 W = Ø100 mm × 211 mm body (overall height 291.4 mm)

Protection & lifetime

Warranty: 5 years
Location: Dry location (indoor)

Configurations / SKUs

SKU	Wattage	Luminous flux (±10%)	Efficacy	CCT by DIP (5)	Beam (lens)	Body Ø	Voltage	Dimming
CL-TL11-10W-5CCT	10 W	800–1,000 lm	80–100 lm/W	2700–5000 K	24 / 30 / 36 / 60°	Ø65 mm	120 VAC	Triac
CL-TL11-15W-5CCT	15 W	1,500 lm	100 lm/W	(same as 5CCT)	24 / 30 / 36 / 60°	Ø85 mm	120 VAC	Triac
CL-TL11-20W-5CCT	20 W	2,000 lm	100 lm/W	(same as 5CCT)	24 / 30 / 36 / 60°	Ø85 mm	120 VAC	Triac
CL-TL11-25W-5CCT	25 W	2,500 lm	100 lm/W	(same as 5CCT)	24 / 30 / 36 / 60°	Ø85 mm	120 VAC	Triac
CL-TL11-30W-5CCT	30 W	3,000 lm	100 lm/W	(same as 5CCT)	24 / 30 / 36 / 60°	Ø100 mm	120 VAC	Triac

Swipe the table to see all columns →

Ordering code

CL-TL11-{wattage}W-5CCT wattage: 10 · 15 · 20 · 25 · 30 (W) 5CCT: 2700 / 3000 / 3500 / 4000 / 5000 K selectable by DIP switch body Ø: 10W→Ø65 · 15/20/25W→Ø85 · 30W→Ø100 (mm)

Differentiator

A single fixture adjusts color temperature (5 CCTs via DIP) and beam angle (interchangeable lens) right on site: scene flexibility without replacing the head, with CRI 90+ and TRIAC dimming

Ideal buyer

Interior designers and specifiers for retail, hospitality and corporate projects · electrical contractors on commercial projects · owners of stores, restaurants and premium homes looking for flexible accent lighting on track
