Commercial
CL TL 12
One head, any angle: track light with hand-adjustable 24°–60° zoom
LED accent track light for retail, offices, hospitality and architectural spaces, with a zoom-type beam adjustable from 24° to 60° by turning the front bezel (no tools or lenses), plus 5 selectable CCTs (2700–5000 K) and a 3-wattage switch. CRI 90, TRIAC dimmable, 120 V AC and three sizes (Ø50/Ø65/Ø85 mm) compatible with H/J/L track. cETLus certified (Intertek), listed for the US and Canada. The solution when the optimal angle is not yet defined in the specification.
Certifications
Does your project require another standard? We build to your specification.
Photometric data (IES/LDT) and datasheet available on request: we send them in under 24 h. Or write to us by email →
Design your space with the photometric studyBetaCheck that your project meets the norm: free, in minutes.Your configuration
Updates with your selection in “Configure & add to quote”
Configure & add to quote
Power
Light color
We manufacture any colour temperature. If the one your project needs isn't listed, ask for it and we'll build it.
Mounting
Other / extra requirement
Quantity
- (1) 24°–60° beam zoom adjustable on site (from spot to wash without changing the fixture), the key differentiator · (2) 5 CCTs + 3 wattages selectable on the same head, adjustable on site without changing the fixture · (3) CRI 90 for true color on products, art and food · (4) optional anti-glare honeycomb for UGR<14 · (5) TRIAC dimming and versatile mounting (H/J/L track, suspended, surface, recessed) · (6) cETLus certification (Intertek) listed for the US and Canada, recognized electrical safety backing.
Specifications
Electrical specifications
- Wattage
- 6–30 W
- Input voltage
- AC 120
- Dimming
- Yes: TRIAC (dimmable)
- Driver
- Integrated TRIAC driver
- LED type
- LED
Photometric specifications
- Wattage
- 6–30 W
- Luminous flux
- 540–850 lm (Ø50) · 850–1,700 lm (Ø65) · 2,000–2,800 lm (Ø85): see SKU table
- Efficacy
- 90–100 lm/W
- CCT
- 2700–5000 K
- CRI
- Ra 90
- Beam angle
- 24° / 60°
- UGR
- < 14 with anti-glare honeycomb accessory
Physical, materials & mounting
- Diffuser / optics
- Zoom optic adjustable by the front bezel (24°–60°)
- Hardware
- Rotating 3-in-1 track adapter
- Finish / color
- Black or white
- Dimensions
- Ø50 × 232 mm · Ø65 × 260 mm · Ø85 × 275 mm (overall length with adapter; head 162 / 190 / 205 mm)
- Mounting
- Track (3-in-1 adapter compatible with H, J or L track) · installation options: pendant (suspended), surface, recessed and track
Protection & lifetime
- Warranty
- 5 years
Configurations / SKUs
| SKU | Head Ø | Wattage switch | Luminous flux (per step) | Efficacy | CCT (selector) | Beam angle | Dimensions (Ø × length) |
|---|---|---|---|---|---|---|---|
| CL-TL12-10W-ZOOM-5CCT | Ø50 mm | 6–10 W | 850 / 680 / 540 lm | 90 lm/W | 2700–5000 K | 24° / 60° | Ø50 × 232 mm (head 162 mm) |
| CL-TL12-20W-ZOOM-5CCT | Ø65 mm | 10–20 W | 1,700 / 1,350 / 850 lm | 90 lm/W | 2700–5000 K | 24° / 60° | Ø65 × 260 mm (head 190 mm) |
| CL-TL12-30W-ZOOM-5CCT | Ø85 mm | 20–30 W | 2,800 / 2,500 / 2,000 lm | 100 lm/W | 2700–5000 K | 24° / 60° | Ø85 × 275 mm (head 205 mm) |
Swipe the table to see all columns →
Differentiator
The angle is adjusted by hand in the field (24°–60°): the same fixture handles accent and wash, and absorbs specification changes without replacing equipment.
Ideal buyer
Lighting designers and interior designers · retail/visual merchandising · hospitality and corporate project managers who need angle flexibility without re-specifying.
